Converting from lead-acid to lithium-ion is easy, cost effective and increases the productivity.
F80420 can be opportunity charged for its fast and efficient charging, so it is the best solution for multi-shift operation. When it’s recharged in a short time, such as changing a shift or taking a break, your forklifts can always remain in service when needed. With the advanced LiFePO4 batteries, you have no maintenance to do, you can get rid of a regular expense and clumsy handing.
The batteries can withstand a high number of load cycles and have electronic controllers that ensure their reliability and safety. You can benefit from 10 years battery life and 5 years warranty for its ongoing savings on energy, equipment, labour and downtime.
Opportunity charge for multi-shift applications
Zero maintenance, no need for water top-ups or electrolyte checks
5 years warranty to ensure a reliable service
No battery swapping for multi-shift operations
No ventilation systems required
Automated components with reliable quality
No charging rooms - easy safe to recharge
Batteries last as long as your truck
In daily operations, F80420 can be charged even during short breaks, effectively increasing productivity. Suited to working in both hot and cold environments, they deliver an all-round solution to material handling. Suitable for CLASS 1 electric heavy duty counterbalance forklifts.
In daily operations, F80420 can be charged even during short breaks, effectively increasing productivity. Suited to working in both hot and cold environments, they deliver an all-round solution to material handling. Suitable for CLASS 1 electric heavy duty counterbalance forklifts.
Intelligent BMS automatically prevents excessive discharge, charge, voltage and temperature...
4G module for software upgrading, remote monitoring and diagnosing.
| Nominal Voltage / Discharge Voltage Range |
80V (80V) |
Nominal Capacity |
420 Ah |
|
Stored Energy |
33.6 kWh |
Dimension(L×W×H) For Reference |
36.9×31.4×30.6 inch (938×798×778 mm) |
|
Weight lbs.(kg) No Counterweight |
903 lbs. (410 kg) |
life Cycle |
>3,500 times |
|
Continuous Discharge |
320 A |
Maximum Discharge |
450 A (5s) |
|
Charge |
-4°F~131°F ( -20°C ~ 55°C) |
Discharge |
-4°F~131°F ( -20°C ~ 55°C) |
|
Storage (1 month) |
-4°F~113°F ( -20°C~45°C) |
Storage (1 year) |
32°F~95°F ( 0°C~35°C) |
|
Casing Material |
Steel |
IP Rating |
IP65 |
